| Specification |
-
Type
Digital camera with support for interchangeable lenses
-
Lens Mount
-
Effective Pixels
-
Sensor Size
-
Image Sensor Format
-
Image Sensor Type
-
Total Pixels
-
Dust-Reduction System
Image Dust Off reference data (NX Studio software required)
-
Image Area (pixels)
DX-format
(L) 5,568 x 3,712
(M) 4,176 x 2,784
(S) 2,784 x 1,856
1:1 (16 x 16)
(L) 3,712 x 3,712
(M) 2,784 x 2,784
(S) 1,856 x 1,856
16:9 (36 x 20)
(L) 5,568 x 3,128
(M) 4,176 x 2,344
(S) 2,784 x 1,560
Photographs taken during movie recording at a frame size of 3,840 x 2,160:
3,840 x 2,160
Photographs taken during movie recording at other frame sizes: 1,920 x 1,080:
1,920 x 1,080
-
File Format Still Images
NEF (RAW): 12 or 14 bit
JPEG: JPEG-Baseline compliant with fine (approx. 1:4), normal (approx. 1:8), or basic (approx. 1:16) compression
NEF (RAW) + JPEG: Single photograph recorded in both NEF (RAW) and JPEG formats
-
Storage Media
SD (Secure Digital) and UHS-I compliant SDHC and SDXC memory cards
-
File System
-
Shutter Type
Electronically-controlled vertical-travel focal-plane mechanical shutter; electronic front-curtain shutter; electronic shutter
-
Shutter Speed
1/4000 – 30 sec. (step of 1/3 EV), bulb, time
-
Flash Sync Speed
Up to: X=1/200 sec.; synchronizes with shutter at 1/200 sec. or slower; Auto FP High-Speed sync supported
-
Top Continuous Shooting Speed at Full Resolution
-
Top Continuous Shooting Speeds
-
Exposure Metering System
TTL metering using camera image sensor
-
Metering Range
Spot metering: -4 to +17 EV
-
Exposure Compensation
–5 – +5 EV, Increment of 1/3 EV
-
Exposure Lock
Luminosity locked at detected value
-
Picture Control
Auto
Flat
Landscape
Monochrome
Neutral
Portrait
Standard
Vivid
Creative Picture Controls: (Dream, Morning, Pop, Sunday, Somber, Dramatic, Silence, Bleached, Melancholic, Pure, Denim, Toy, Sepia, Blue, Red, Pink, Charcoal, Graphite, Binary, Carbon)
Selected Picture Control can be modified
Storage for custom Picture Controls
-
Multiple Exposure
Yes
Add
Average
Lighten
Darken
-
ISO Sensitivity
ISO 100 - 51,200 in steps of 1/3 EV
Can also be set to approx. 1 EV above ISO 51200 (ISO 102400 equivalent) or to approx. 2 EV above ISO 51200 (ISO 204800 equivalent)
Auto ISO sensitivity control available
-
Active D-Lighting
Can be selected from:
Auto
Extra High
High
Normal
Low
Off
-
Active D-Lighting Bracketing
-
Autofocus System
Hybrid phase-detection/contrast AF
-
Detection Range
-4.5 to +19 EV (without low-light AF: -3 to +19 EV)
Measured in photo mode at ISO 100 and a temperature of 20 °C/68 °F using single-servo AF (AF-S) and a lens with a maximum aperture of f/1.8
-
Lens Servo
Autofocus (AF): Single-servo AF (AF-S); continuous-servo AF (AF-C); AF mode auto-switch (AF-A; available only in photo mode); full-time AF (AF-F; available only in movie mode); predictive focus tracking
Manual focus (M): Electronic rangefinder can be used
-
Focus Point
209 (single-point AF)
Number of focus points available in photo mode with single-point AF selected for AF-area mode and DX selected for image area
-
AF-Area Mode
Pinpoint
Single-Point
Dynamic-area AF
Wide-area AF (S)
Wide-area AF (L)
Wide-area AF (L-people)
Wide-area AF (L-animals)
Auto-area AF
Auto-area AF (people)
Auto-area AF (animals)
-
Focus Lock
-
Flash Control
TTL: i-TTL flash control; i-TTL balanced fill-flash is used with matrix, center-weighted, and highlight-weighted metering, standard i-TTL fill-flash with spot metering
-
Flash Sync Modes
Front-curtain sync
Rear-curtain sync
Red-eye reduction
Red-eye reduction with slow sync
Slow sync
Off
-
Flash-ready Indicator
Lights when optional flash unit is fully charged; flashes as underexposure warning after flash is fired at full output
-
Accessory Shoe
ISO 518 hot-shoe with sync and data contacts and safety lock
-
Nikon Creative Lighting System (CLS)
i-TTL flash control, optical Advanced Wireless Lighting, FV lock, Color Information Communication, Auto FP High-Speed Sync
-
White Balance
Auto (3 types)
Choose color temperature (2,500 K–10,000 K)
Cloudy
Direct sunlight
Flash
Fluorescent (3 types)
Incandescent
Natural light auto
Preset manual (up to 6 values can be stored), all except choose color temperature with fine-tuning
Shade
-
White Balance Bracketing
-
Movie Metering
TTL exposure metering using main image sensor
-
Movie Maximum Recording Time
-
Movie File Format
-
Movie Video Compression
H.264/MPEG-4 Advanced Video Coding
-
Movie Audio Recording Format
-
Movie
4K UHD 3,840 × 2,160 /30p/25p/24p
Full HD 1,920 x 1,080 /120p/100p/60p/50p/30p/25p/24p
Actual frame rates for 120p, 100p, 60p, 50p, 30p, 25p, and 24p are 119.88, 100, 59.94, 50, 29.97, 25, and 23.976 fps respectively
Quality selection (normal/m) available at all sizes except 3840 × 2160, 1920 × 1080 120p/100p, and 1920 × 1080 slow-motion, when quality is fixed at m
-
Movie Audio
Built-in stereo or external microphone with attenuator option; sensitivity can be adjusted
-
Movie ISO
Auto ISO sensitivity control (ISO 100 to 25,600)
M: Manual selection (ISO 100 to 25,600 in steps of 1/3 or 1/2 EV); auto ISO sensitivity control (ISO 100 to 25,600) available with selectable upper limit
Auto ISO sensitivity control (ISO 100–25600)
-
Movie Active D-Lighting
Can be selected from:
Auto
Extra High
High
Normal
Low
Off
-
Time Code
-
Movie e-VR
-
Movie HDMI Output
-
Movie Focus Peaking
-
Movie Highlight Display (Zebras)
-
Time-Lapse Movie
-
AF for Movie
-
Monitor Size
-
Monitor Resolution
-
Monitor Type
Vari-angle TFT touch-sensitive LCD with 170° viewing angle, approximately 100% frame coverage
Color balance and 11-level manual brightness controls
-
Playback Functions
Full-frame and thumbnail (4, 9, or 72 images or calendar)
Highlights
Histogram Display
Location Data Display
Movie Playback
Photo and/or Movie Slide Shows
Photo Information
Picture Rating
Playback with Playback Zoom
Playback Zoom Cropping
Photo and/or video slide shows
-
Interface
USB: Type C USB connector (SuperSpeed USB); connection to built-in USB port is recommended
Type D HDMI connector; Stereo mini-pin jack (3.5 mm diameter; plug-in power supported)
-
Wi-Fi Functionality
Standards: IEEE 802.11b/g/n (Africa, Asia, Bolivia, and Oceania)
Standards: IEEE 802.11b/g/n/a/ac (Europe, U.S.A., Canada, Mexico)
Standards: IEEE 802.11b/g/n/a (other countries in the Americas)
Operating frequency: 2412–2462 MHz (channel 11; Africa, Asia, Bolivia, and Oceania)
Operating frequency: 2412–2462 MHz (channel 11) and 5180–5805 MHz (other countries in the Americas)
Operating frequency: 2412–2462 MHz (channel 11) and 5180–5825 MHz (U.S.A., Canada, Mexico)
Authentication: Open system, WPA2-PSK
Maximum output power (EIRP):
2.4 GHz band: 4.5 dBm
5 GHz band: 6.8 dBm (countries in the Americas)
-
Smart Device App Connectivity
-
Bluetooth
Communication protocols: Bluetooth Specification
Version 4.2
Operating frequency: Bluetooth: 2402–2480 MHz
Bluetooth Low Energy: 2402–2480 MHz
Maximum output power (EIRP)
Bluetooth –1.0 dBm
Bluetooth Low Energy: –2.5 dBm
-
Supported Languages
English
French
Portuguese (Brazil)
Spanish
-
Battery / Batteries
One EN-EL25 rechargeable Li-ion battery
-
Battery Life (shots per charge)
330 shots (CIPA)
Movies: Approx. 75 min. of movie recording
-
AC Adapter
EH-7P charging AC adapter (available separately)
-
Battery Charger
MH-32 Battery Charger (available separately)
-
Tripod Socket
-
Approx. Dimensions (Width x Height x Depth)
5.1 in.
(128 mm)
x 2.9 in.
(73.5 mm)
x 2.4 in.
(59.5 mm)
-
Approx. Weight
-
Operating Environment
Temperature 0 °C–40 °C (+32 °F–104 °F)
Humidity: Less than 85% (no condensation)
|
|---|
